Alpha Deluxe Series 3/4" CED x 2-1/2" LOC Compression Chipbreaker

Write a Review
Brand:
SKU:
AD750.2500.24SCB
$575.19
Alpha Deluxe Series 3/4" CED x 2-1/2" LOC Compression Chipbreaker
Alpha Deluxe Series Solid Carbide High Wear Compression Chipbreaker Finishing Tool
Materials: Raw and laminated plywood, solid wood and composite wood materials

Application: The AD750.2500.24SCB is a compression chipbreaker finishing tool design featuring a durable 3/4" cutting diameter x 2-1/2" (3.33xD) length of cut, Black Hawk tool coating and a medium upshear length.  These features make the AD750.2500.24SCB an excellent choice for profile routing fibrous and fiber filled materials up to 2-1/2" thick when smooth top, bottom and side edge finishes are required.  The 1" upshear length improves chip evacuation while still providing downward cutting pressure to minimize or eliminate part movement.  The AD750.2500.24SCB can also be used for part cut out operations when utilizing a 25% to 50% chip load reduction.
  • Black Hawk Performance tool coating and Super Prep 2 edge finish provides superior wear resistance and a low friction surface finish, improving edge durability and chip evacuation.
  • High wear, shock and vibration resistant solid carbide tool design.
  • High tolerance shank for high accuracy tool holding systems.
  • Designed and manufactured in the USA!
Mill Diameter:
3/4"
Shank Diameter:
3/4"
Length of Cut:
2-1/2"
Overall Length:
5"
Flutes:
2
Flute Style:
Compression chipbreaker
Material:
Solid Carbide
Coating:
Nanotech3P
